SPECIFICATION:

Rating: 15A 125V AC / 10A 250V AC

Vithstand Voltage: AC 1500 V 1 Minute

Insulation Resistance: 200 MΩ Mim. 500V DC

Contact Resistance: 20MΩ Max.

FUNCTION:

3PDT 9PINS

PL-708-1: ON-ON

PL-708-1A: (ON)-ON

PL-708-2: ON-OFF-ON

PL-708-2A: (ON)-OFF-ON

PL-708-2B: (ON)-OFF-(ON)

□=Terminal Type

H1=Screw Type (7.0mm)   H4=187" (4.8mm)

H2=Screw Type (6.8mm)   H5=250" (6.3mm)

H3=Solder Type
