SPECIFICATION:

Rating: 15A 125V AC / 10A 250V AC

Mounting Hole: 28.5 x 13.6 mm

Function: ON - OFF with Lamp

Terminal Type: #250 Terminal (6.3mm)

Insulation Resistance: 500 MΩ Mim.

Contact Resistance: 30MΩ Max.

Withatand Voltage: AC 1,500 V 1 Minute

Mechanical Life: 6,000 cycles
