SPECIFICATION:

Rating: 0.5A 100V AC

Screw Hole: 20mm

PIN Pitch: 4.0mm

Operating Force: 300 ± 100gf

Insulation Resistance: 100 MΩ Mim. 500V DC

Contact Resistance: 20MΩ Max.

Dielectric Strength: AC 500 V 1 Minute

Approvals : RoHS
