SPECIFICATION:
Rating: 50mA 12V DC
Operating force: 160gf , 250gf
Dielectric strength: AC 250 V 1 minute
Insulation resistance: 100 MΩ DC 250 V
Contact resistance: 50 MΩ Min.
Operating Temperature: -15oC ~ +60oC
Mechanical Life: 50,000 cycles
Electrical Life: 50,000 Cycles
FUNCTION:
□ = H (mm)
01 = 6.2 x 6.2 x 3.1 mm
02 = 6.2 x 6.2 x 3.8 mm
Approvals: RoHS
