SPECIFICATION:

Rating: 5/80A 250V AC

Actuator Length: 18mm

Screw Hole: 20mm

Terminal Type: Solder
Operating Force: 500 ± 200gf

Insulation Resistance: 500 MΩ Mim. 500V DC

Contact Resistance: 50MΩ Max.

Withatand Voltage: AC 2,000 V 1 Minute

Operating Temperature: -25^oC ~ +65^oC

Mechanical Life: 100,000 cycles

Electrical Life: 6,000 cycles

Approvals : RoHS,UL,CSA,VDE,SEMKO,NEMKO,
                   DEMKO,FIMKO,CQC
