SPECIFICATION:
Max Contact Roltage: 50W
Max Switching Current : 3A
Max Switching Voltage: 7500V DC / 10000V DC
Min Breakdown Voltage: 10000V DC / 15000V DC
Max Curry Current: 4.0A
Max Contact Resistance: 100mΩ
Operate Time: 3.2ms
Release Time: 1.5ms
Pull in Value: 100~150AT / 140~170AT
FUNCTION:
Glass Length: 53.3 x Φ5.3 max
Overall Length: 81.8 x Φ0.5 max
Approval: RoHS
